Xi EP LV 200W 3.0-6.7A WL I195

Xitanium Essential Programmable (EP) LED drivers are designed for maximum reliability and flexibility, making it a preferred choice for
different Outdoor applications. The key feature AOC (Adjustable Output Current ) can be programmed with the new e-set tool, a simple and
fast way to configure the driver without the need to power on the driver and without the need for any software configuration.
Xitanium EP Low Voltage (LV) drivers are specifically designed for low voltage outdoor applications. Having high surge immunity, these
durable, independently housed drivers deliver consistent, high performance to luminaires. It is an ideal solution for OEMs who need reliable,
adjustable output current in a rugged independent form factor.


Product Detail

Product Tags

Xi-EP-LV-200W-3.0-6.7A-WL-I195_01

Xitanium Outdoor Essential Programmable Low Voltage LED Drivers

Xi EP LV 200W 3.0-67A WL I195

9290 033 92980

Xitanjum Essential Programmable (EP) LED drivers are designed for maximum reliability and flexibility, making it a preferred choice fordifferent Outdoor applications. The key feature AOC (Adiustable 0utput Current ) can be programmed with the new e-set tool, a simple andast way to conficure the driver without the need to power on the driver and without the need for any software conficuration.Xitanium EP Low Voltage (LV) drivers are specifically designed for low voltage outdoor applications. Having high surge immunity, thesedurable, independently housed drivers deliver consistent, high performance to luminaires. t is an ideal solution for 0EMs who need reliableadjustable output current in a rugged independent form factor.

Benefits

·Low voltage/high current output fits low voltage outdoor applications
AOC (Adjustable Output Current) gives full flexibility to outputdifferent currents to spec-in different projects
·Compact housing saves luminaire space
·Easy adjustment of output current/voltage saves time andabor cost
·Robust design offers peace of mind and saves maintenancecost
·IP rated housing allows use in a non-fully sealed gearbox

Features

·100-277V input voltage
·Low voltage/high current output
·Adjustable Output Current (AOC)
·Compact housing dimensions
·Digital way to adjust output current called e-set too
·Robust specifications for moisture, vibration, andtemperature protection
·IP67

Application

·Road and street lighting
·Area and flood lighting
·Tunnel lighting
·High-bay lighting

Xi-EP-LV-200W-3.0-6.7A-WL-I195_03
Xi-EP-LV-200W-3.0-6.7A-WL-I195_05
Xi-EP-LV-65W-0.9-2.2A-WL-I120_05
Xi-EP-LV-200W-3.0-6.7A-WL-I195_07
Xi-EP-LV-65W-0.9-2.2A-WL-I120_08
Xi-EP-LV-200W-3.0-6.7A-WL-I195_10
Xi-EP-LV-65W-0.9-2.2A-WL-I120_13
Xi-EP-LV-200W-3.0-6.7A-WL-I195_12
Xi-EP-LV-200W-3.0-6.7A-WL-I195_14
